Embed Scripting Languages in PL/SQL Programs

One of the goals of creating an interpreter written in PL/SQL to execute a custom language was for our use in our tools. We wanted to be able to ship PL/SQL and customise it after its deployed without re-compiling the PL/SQL but also to add a secondary level of security.

Each piece of PL/SQL that is part of an application is visible to anyone who has access to the database in USER_SOURCE, ALL_SOURCE and DBA_SOURCE depending on privileges. Even if the code is wrapped then it can be unwrapped although even if 10g and above is easy to unwrap and no unwrappers are available for 9ir2 and below it is still possible; I can do it!
What I wanted was a combination of two things:

  • Use code in our PL/SQL that is not visible in the SOURCE$ tables or views so that someone with direct database access cannot as easily work out how our code works

  • Extend an application at run time without the need to re-compile the PL/SQL or allow the user of the application to do so. If we let end users change the PL/SQL the there is a
    danger of security issues and the need to allow elevated access to the PL/SQL interface


If we allow end users or more likely power users to extend a PL/SQL application at run time then we must control the level of extension and how its extended and what features or aspects of the original application are exposed to the scripting interface.

In other words the end user/customiser can write as much or as little scripting language as they want BUT we as designers control how the script language is exposed to the PL/SQL application.

A good example/model is the embedding of Lua into C programs. We do this by embedding Lua into all of our products so that rules in PFCLScan can be written in Lua or generic obfuscation can be done in PFCLObfuscate using Lua and rules in our PL/SQL code analyser PFCLCode can be written in Lua; in fact all of our products because they are built on PFCLScan can use Lua as part of then checks and functionality.

Lua is a good example of extending a product. In the case of PFCLScan where the core engine is written in C we have embedded Lua.

The extension to add Lua is done at compile time of our C based applications; in the case of PFCLScan we compile in the Lua engine and we provide an interface to the Lua engine so that scripts can be loaded and then executed. To be able to do something useful we needed to extend Lua to give it access to our C based engine. We added C functions written using the Lua API to extend Lua from C so that when they are also compiled in with the Lua engine scripts can be written in Lua that also execute code against our engine BUT from Lua.
Some examples of the extension functions we added to Lua for PFCLScan are first that we add functions to Lua written in C:

  • PFCLOpen() â€" this is used to open previous checks so that results can be parsed and worked on in Lua

  • PFCLLine() â€" we can read one line of results to split into columns of data

  • PFCLSplit() â€" can be used to split a line of data based on a passed in separator

  • PFCLPrint() â€" print a line of data to our scanner output


Second we also pass in tables of data from the C engine as Lua is executed so that data items processed in C can be accessed via the Lua scripts. In our code analyser in PFCLCode for instance we can access the lexer and parser output as a table of data and in all of our tools we pass flags to Lua that can then be used in Lua. One example is a debug flag so that if “trace†is enabled in our engine then a debug flag is passed to Lua so that a “trace†flag can also be enabled or not in Lua and then debug statements will write to the output to aid debugging of Lua scripts.

The third thing that we do is provide some Lua libraries written in Lua that can be included in scripts run by the tool (in user space â€" i.e. we do not need to recompile the C code) to help with common tasks such as checking if a file exists or reading and writing files.

The goal with PL/SQL applications including APEX is to do the same thing as Lua with C code applications. We have created a simple language interpreter written in PL/SQL. A few articles on writing a simple language interpreter in PL/SQL are on my website

A simple script showing a nested loop is here:

declare
lv_prog varchar2(32767):=q'[
LET m=2
LET x=1
PRINT "Start of tests"
PRINT "=================="
LOOP
LET y=1
LOOP
PRINT "x, y is [";x;",";y;"]"
IF y>m THEN
EXIT
FI
LET y=y+1
POOL
IF x>m THEN
EXIT
FI
LET x=x+1
POOL
PRINT "=================="
PRINT "End of Tests"
END
]';
begin
--
pfclscript.init(true,1);
pfclscript.run(lv_prog);
--
end;
/

And the output is here:

SQL> @interp
Start of tests
==================
x, y is [1,1]
x, y is [1,2]
x, y is [1,3]
x, y is [2,1]
x, y is [2,2]
x, y is [2,3]
x, y is [3,1]
x, y is [3,2]
x, y is [3,3]
==================
End of Tests

PFCLScript Execution Time (Seconds) : +000000 00:00:11.041386000
SQL>

To add this as a language to any PL/SQL application including Apex we need to do:

  • ship the interpreter package header and body with the PL/SQL application in a separate schema

  • Lock the interpreter schema, ensure only permission to execute is given to the PL/SQL application. Use other features such as “accessible by†clause to ensure that the interpreter cannot be started outside of its designed use

  • Add the init() and run() calls to the interpreter in your PL/SQL application where you choose to use them

  • Store and allow scripts to be loaded as data in your PL/SQL application and arrange that they can be chosen and executed as needed

  • Create a simple API into your application that can be used from the interpreter as package calls to expose only the features/functionality as needed. These package procedure calls can access data/functions in the PL/SQL application and this API should be in a separate schema. Grant access on the PL/SQL application to this schema

  • Create the “register calls†in your PL/SQL application after init() and before run() to register the interpreter function names that map to the API you created above


A simple call sequence inside your application would be:

…
begin
--
pfclscript.init(true,1);
pfclscript.register(‘PFCLFUNCA’,’API.FUNCA’);
pfclscript.register(‘PFCLFUNCB’,’API.FUNCB’);
pfclscript.run(lv_prog);
--
end;
…

The register() function in effect creates a new ID internally in the interpreter for the “PFCLFUNA†and “PFCLFUNCB†and these are mapped to actual PL/SQL functions in the interface PL/SQL API created. This now means that a script can be created that executes in our script engine that uses these functions to access features or data in the actual PL/SQL or Apex application.

To the script, these just look like function calls. The designer of the PL/SQL or Apex application decides where to run the script and what features to expose.
Data can be passed in by the script writer in the form or parameters to the script function and these parameters are then passed to the registered PL/SQL API functions.
Libraries of script code can be added easily, simply by prepending them to the script to run. We do not currently have “includeâ€, “require†type keywords but they can be simulated by pre-pending the library code.

The engine can also pass data to the script engine in a similar way to Lua but in essence in a simpler day. We can do this in two ways. The first by setting up internal data in the API functions or the second by passing data as script variables again pre-pended to the script to run

#oracleace #sym_42 #plsql #apex #scripting #compiler #interpreter #oracle #security

The search for existing encryption and wallets in the database

In the first blog in this series we discussed the main issue with using DBMS_CRYPTO to encrypt data within the database. This is the lack of key management provided by Oracle natively for use with this package. I had intended to make the second part the design of a key vault for use with DBMS_CRYPTO or DBMS_OBFUSCATION_TOOLKIT but I decided to switch up part two as an investigation into whether its likely that there is any access to wallets or encryption that could be used where key management is already present. As we said in the last post if we could use a wallet then some level of key management is done, in that we have a wallet password we can cycle and if we can store a master key in a wallet then we could cycle the master key and we can then store column or other keys elsewhere as they are encrypted.

Here is the table of posts (now 6 parts):

  1. Part 1: Encryption Key Management with DBMS_CRYPTO - Discuss the problem in general and the need to encrypt data in the database

  2. Part 2: The search for wallets- The search for wallet interfaces in the database

  3. Part 3: - We will present a simple solution design to store an encryption key for use with DBMS_CRYPTO and discuss some of its flaws

  4. Part 4: - Lets build a key vault

  5. Part 5: - Protecting the key vault

  6. Part 6: - Using the key vault with DBMS_CRYPTO and SQL


If we look in the database for any objects that include the name WALLET we get:

SQL> col owner for a30
SQL> col object_name for a30
SQL> col object_type for a30
SQL> set lines 220
SQL> l
1* select owner,object_name,object_type from dba_objects where object_name like '%WALLET%'
SQL> select owner,object_name,object_type from dba_objects where object_name like '%WALLET%' and object_type not in ('INDEX','SYNONYM');

OWNER OBJECT_NAME OBJECT_TYPE
------------------------------ ------------------------------ ------------------------------
SYS GV_$WALLET VIEW
SYS V_$WALLET VIEW
SYS V_$ENCRYPTION_WALLET VIEW
SYS GV_$ENCRYPTION_WALLET VIEW
SYS NACL$_WALLET TABLE
SYS DBA_WALLET_ACLS VIEW
SYS CDB_WALLET_ACLS VIEW
SYS DBA_WALLET_ACES VIEW
SYS CDB_WALLET_ACES VIEW
SYS USER_WALLET_ACES VIEW
SYS NACL$_WALLET_EXP VIEW

OWNER OBJECT_NAME OBJECT_TYPE
------------------------------ ------------------------------ ------------------------------
SYS NACL$_WALLET_EXP_TBL TABLE

12 rows selected.

SQL>

Nothing looks useful here in terms of our goal. If we now search for PL/SQL:

SQL> select owner,object_name,procedure_name
2 from dba_procedures where procedure_name like '%WALLET%';

OWNER OBJECT_NAME PROCEDURE_NAME
------------------------------ ------------------------------ --------------------------------------------------------------------------------------------------------------------------------
SYS UTL_HTTP SET_AUTHENTICATION_FROM_WALLET
SYS UTL_HTTP SET_WALLET
SYS DBMS_ISCHED GET_AGENT_WALLET_LOCATION
SYS DBMS_GSM_FIX UPDATEWALLETFORBACKUP
SYS DBMS_NETWORK_ACL_ADMIN GET_WALLET_ACLID
SYS DBMS_NETWORK_ACL_ADMIN SET_WALLET_ACL
SYS DBMS_NETWORK_ACL_ADMIN REMOVE_WALLET_ACE
SYS DBMS_NETWORK_ACL_ADMIN APPEND_WALLET_ACL
SYS DBMS_NETWORK_ACL_ADMIN APPEND_WALLET_ACE
SYS DBMS_NETWORK_ACL_ADMIN UNASSIGN_WALLET_ACL
SYS DBMS_NETWORK_ACL_ADMIN ASSIGN_WALLET_ACL

OWNER OBJECT_NAME PROCEDURE_NAME
------------------------------ ------------------------------ --------------------------------------------------------------------------------------------------------------------------------
SYS KUPU$UTILITIES CHECK_ENCRYPTION_WALLET
SYS KUPU$UTILITIES_INT CHECK_ENCRYPTION_WALLET
XDB DBMS_XDB_ADMIN INSTALLDEFAULTWALLET

14 rows selected.

SQL>

At first glance UTL_HTTP and KUPU$UTILITIES may be useful but UTL_HTTP may not be useful as its a web based use and not encryption. you need to create a wallet with orapki or openssl and whislt UTL_HTTP can be used to open the wallet and set the wallet only it does not seem to have a way to add an encryption key or retrieve that key - its for SSL certificates.

What about certificate based objects:

SQL> select owner,object_name,procedure_name
2 from dba_procedures where procedure_name like '%CERT%';

OWNER OBJECT_NAME PROCEDURE_NAME
------------------------------ ------------------------------ --------------------------------------------------------------------------------------------------------------------------------
SYS DBMS_ISCHED ADD_AGENT_CERT
SYS DBMS_USER_CERTS DROP_CERTIFICATE
SYS DBMS_USER_CERTS ADD_CERTIFICATE
SYS DBMS_ISCHED_REMOTE_ACCESS ADD_AGENT_CERTIFICATE

SQL>

and PL/SQL:

SQL> select owner,object_name,procedure_name
2 from dba_procedures where object_name like '%CERT%';

OWNER OBJECT_NAME PROCEDURE_NAME
------------------------------ ------------------------------ --------------------------------------------------------------------------------------------------------------------------------
SYS DBMS_USER_CERTS ADD_CERTIFICATE
SYS DBMS_USER_CERTS DROP_CERTIFICATE
REMOTE_SCHEDULER_AGENT ADD_AGENT_CERTIFICATE
SYS DBMS_USER_CERTS

SQL>

We could use utl_http to open a wallet; first create the wallet with orapki and then use ACLs to assign the wallet to the encryption and use a certificate as a key - but certificate cannot be accessed via PL/SQL, only used in a HTTPS web transaction from UTL_HTTP

If we go back to KUPU$UTILITIES and KUPU$UTILITIES_INT and have a more detailed look at the first package:

SQL> desc sys.kupu$utilities
PROCEDURE BITCLR
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
MASK1 NUMBER IN/OUT
MASK2 NUMBER IN
PROCEDURE BITSET
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
MASK1 NUMBER IN/OUT
MASK2 NUMBER IN
FUNCTION BITSETRET RETURNS NUMBER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
MASK1 NUMBER IN
MASK2 NUMBER IN
PROCEDURE BITSOC
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
MASK1 NUMBER IN/OUT
MASK2 NUMBER IN
EXPR BOOLEAN IN
FUNCTION BITTST RETURNS BOOLEAN
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
MASK1 NUMBER IN
MASK2 NUMBER IN
FUNCTION BITTSTANY RETURNS BOOLEAN
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
MASK1 NUMBER IN
MASK2 NUMBER IN
FUNCTION BOOLTOINT RETURNS BINARY_INTEGER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
BOOLVAL BOOLEAN IN
TRUEVAL NUMBER(38) IN DEFAULT
FUNCTION BOOLTOSTR RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
BOOLVAL BOOLEAN IN
PROCEDURE CHECK_ENCRYPTION_WALLET
FUNCTION CHECK_IF_SHARDED_DB RETURNS NUMBER
FUNCTION CHECK_TBS_FOR_TDECOL_TABS RETURNS NUMBER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
TBS VARCHAR2 IN
PROCEDURE DEBUG
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
STR VARCHAR2 IN
FUNCTION FORMAT_ERROR_STACK RETURNS VARCHAR2
PROCEDURE GET_DB_VERSION
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
DBLINK VARCHAR2 IN
VERSION VARCHAR2 OUT
COMPAT VARCHAR2 OUT
FUNCTION GET_NLS_ALTER_SESSION RETURNS VARCHAR2
FUNCTION GET_PLATFORM_NAME RETURNS VARCHAR2
FUNCTION GET_REMOTE_DBLINK_USER RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
LINK_NAME VARCHAR2 IN
FUNCTION GET_TSTZ_VERSION RETURNS NUMBER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
REMOTE_LINK VARCHAR2(128) IN DEFAULT
FUNCTION REPLACE_XML_VALUES RETURNS CLOB
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
ERROR:
ORA-24328: illegal attribute value


XML_REPL_TAB TABLE OF IN
XML_CLOB CLOB IN
PROCEDURE UPDATEFEATURETABLE
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
UTILITY_NAME VARCHAR2 IN
PROCEDURE UPDATEFEATURETABLE
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
UTILITY_NAME VARCHAR2 IN
ERROR:
ORA-24328: illegal attribute value


FEATURE_INFO TABLE OF IN

SQL>

This package and its internal version are wrapped so we cannot see the source code and they are internal and as far as I can find not documented in any way. There are no references to their use on the internet or in the rdbms/admin folder of the database server. They are most likely used within other SYS packages internally and also in wrapped code. A simple grep of the folder does not locate any publicly visible code that we can see that uses them. The only thing of interest is check_encryption_wallet in the non INT package.

We can check dependencies for kupu$utilities as follows:

SQL> @dep
Enter value for object_to_test: KUPU$UTILITIES
old 3: where referenced_name='&&object_to_test'
new 3: where referenced_name='KUPU$UTILITIES'
Enter value for owner_to_test: SYS
old 4: and referenced_owner='&&owner_to_test'
new 4: and referenced_owner='SYS'

NAME OWNER TYPE
------------------------------ -------------------- ------------------------------
KUPU$UTILITIES SYS PACKAGE BODY
DBMS_METADATA_INT SYS PACKAGE BODY
DBMS_PLUGTS SYS PACKAGE BODY
KUPM$MCP SYS PACKAGE BODY
KUPUTIL PUBLIC SYNONYM

SQL>

Lets describe the internal package:

SQL> desc kupu$utilities_int
PROCEDURE CHECK_ENCRYPTION_WALLET
FUNCTION CHECK_IF_SHARDED_DB RETURNS NUMBER
FUNCTION CHECK_IGNORE_DESC_IN_INDEX RETURNS BOOLEAN
FUNCTION CHECK_TBS_FOR_TDECOL_TABS RETURNS NUMBER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
TBS VARCHAR2 IN
PROCEDURE CREATE_DIRECTORY
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
DIR_PATH VARCHAR2 IN
PROCEDURE DEBUG
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
STR VARCHAR2 IN
FUNCTION DECODE RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
SRC VARCHAR2 IN
PROCEDURE DH_CHECK_DIGESTS
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
SRCDIGEST VARCHAR2(512) IN
TARDIGEST VARCHAR2(512) IN
FUNCTION DH_DECRYPT RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
SRCBUF VARCHAR2 IN
OUTFMT BINARY_INTEGER IN DEFAULT
FUNCTION DH_ENCRYPT RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
SRCBUF VARCHAR2 IN
INPFMT BINARY_INTEGER IN DEFAULT
PROCEDURE DH_FREE_HANDLE
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
FUNCTION DH_GEN_SHARED_KEY RETURNS VARCHAR2(512)
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
PUBKEY VARCHAR2(1024) IN
FUNCTION DH_GET_PUBLIC_KEY RETURNS VARCHAR2(1024)
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
FUNCTION DH_NEW_HANDLE RETURNS NUMBER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
KEY_SIZE NUMBER IN
FUNCTION DIRECTORY_SCAN RETURNS BINARY_INTEGER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
INFILESPEC VARCHAR2 IN
INDEFDIRSPEC VARCHAR2 IN
INSKIPFILEVERIFY BOOLEAN IN DEFAULT
INSUBDIRSEARCH BOOLEAN IN DEFAULT
OUTHASWILDCARD BOOLEAN OUT
INPLSQLARRAY T_DATAFILE_NAMES IN/OUT
INARRAYINDEX BINARY_INTEGER IN
FUNCTION ENCODE RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
SRC VARCHAR2 IN
FUNCTION GET_DP_UPDATE_LOCK RETURNS VARCHAR2
FUNCTION GET_PARAMETER_VALUE RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
NAME VARCHAR2 IN
FUNCTION GET_REMOTE_DBLINK_USER RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
USERID NUMBER IN
LINK_NAME VARCHAR2 IN
FUNCTION GET_SESSION_STAT RETURNS NUMBER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
STATISTIC VARCHAR2 IN
SID NUMBER IN DEFAULT
FUNCTION GET_SHARDED_TABLE_FAMILY_ID RETURNS NUMBER
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
SCHEMANAME VARCHAR2 IN
TABLENAME VARCHAR2 IN
PROCEDURE INTALGCONV
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
ALG BINARY_INTEGER IN
IN_VAL VARCHAR2 IN
OUT_VAL VARCHAR2 OUT
FUNCTION INT_CHECK_IF_SHARDED_DB RETURNS NUMBER
FUNCTION IS_SUPERSET RETURNS BOOLEAN
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
FRCSID BINARY_INTEGER IN
TOCSID BINARY_INTEGER IN
FUNCTION MAX_DATAPUMP_JOBS_PER_PDB RETURNS BINARY_INTEGER
PROCEDURE RELEASE_DP_UPDATE_LOCK
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
SWLOCK_HANDLE VARCHAR2 IN
PROCEDURE SET_DEBUG
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
DEBUG_FLAGS BINARY_INTEGER IN
PROCEDURE SET_KGL_TIME_TO_WAIT_FOR_LOCKS
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
LWAIT_TIME NUMBER IN
FUNCTION TEN_G_LOGON_ALLOWED RETURNS NUMBER
PROCEDURE UPDATEFEATURETABLE
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
UTILITY_NAME VARCHAR2 IN
FEATURE_INFO FEATURE_INFO_T IN
PROCEDURE WRITEAUDITRECORD
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
ACTION BINARY_INTEGER IN
MASTER_ONLY BOOLEAN IN DEFAULT
DATA_ONLY BOOLEAN IN DEFAULT
METADATA_ONLY BOOLEAN IN DEFAULT
DUMPFILE_PRESENT BOOLEAN IN DEFAULT
JOB_RESTARTED BOOLEAN IN DEFAULT
MASTER_TABNAME VARCHAR2 IN
META_JOB_MODE VARCHAR2 IN
JOB_VERSION VARCHAR2 IN
ACCESS_METHOD VARCHAR2 IN
DATA_OPTIONS VARCHAR2 IN
DUMPER_DIRECTORY VARCHAR2 IN
REMOTE_LINK VARCHAR2 IN
TABLE_EXISTS_ACTION VARCHAR2 IN
PARTITION_OPTIONS VARCHAR2 IN
WARNINGS1 VARCHAR2 IN

SQL>

There are quite a few functions and procedures of interest listed here:

FUNCTION ENCODE RETURNS VARCHAR2
FUNCTION DH_GET_PUBLIC_KEY RETURNS VARCHAR2(1024)
FUNCTION DH_NEW_HANDLE RETURNS NUMBER
FUNCTION DH_GET_PUBLIC_KEY RETURNS VARCHAR2(1024)
FUNCTION DH_GEN_SHARED_KEY RETURNS VARCHAR2(512)
PROCEDURE DH_FREE_HANDLE
FUNCTION DH_ENCRYPT RETURNS VARCHAR2
FUNCTION DH_DECRYPT RETURNS VARCHAR2
PROCEDURE DH_CHECK_DIGESTS
PROCEDURE CHECK_ENCRYPTION_WALLET

Of particular interest is the wallet procedure CHECK_ENCRYPTION_WALLET and the encrypt/decrypt functions. We can also check the dependencies of this package:

SQL> @dep
Enter value for object_to_test: KUPU$UTILITIES_INT
old 3: where referenced_name='&&object_to_test'
new 3: where referenced_name='KUPU$UTILITIES_INT'
Enter value for owner_to_test: SYS
old 4: and referenced_owner='&&owner_to_test'
new 4: and referenced_owner='SYS'

NAME OWNER TYPE
------------------------------ -------------------- ------------------------------
DBMS_DATAPUMP SYS PACKAGE BODY
KUPV$FT_INT SYS PACKAGE BODY
KUPP$PROC SYS PACKAGE BODY
DBMS_DATAPUMP_UTL SYS PACKAGE BODY
KUPV$FT SYS PACKAGE BODY
KUPU$UTILITIES SYS PACKAGE BODY
KUPU$UTILITIES_INT SYS PACKAGE BODY
DBMS_METADATA_UTIL SYS PACKAGE BODY
KUPW$WORKER SYS PACKAGE BODY
KUPM$MCP SYS PACKAGE BODY
KUPF$FILE_INT SYS PACKAGE BODY

NAME OWNER TYPE
------------------------------ -------------------- ------------------------------
DBMS_PLUGTS SYS PACKAGE BODY
DBMS_TTS SYS PACKAGE BODY
DBMS_METADATA SYS PACKAGE BODY
DBMS_METADATA_DIFF SYS PACKAGE BODY

15 rows selected.

SQL>

And also look to see what packages use this internal package:

SQL> col referenced_owner for a30
SQL> col referenced_name for a30
SQL> col referenced_type for a30
SQL> select referenced_owner,referenced_name,referenced_type
2 from dba_dependencies
3 where name='KUPU$UTILITIES_INT' and owner='SYS';

REFERENCED_OWNER REFERENCED_NAME REFERENCED_TYPE
------------------------------ ------------------------------ ------------------------------
SYS STANDARD PACKAGE
SYS STANDARD PACKAGE
SYS PLITBLM PACKAGE
SYS DBMS_LOCK PACKAGE
SYS DBMS_UTILITY PACKAGE
SYS DBMS_ASSERT PACKAGE
SYS DBMS_METADATA_UTIL PACKAGE
SYS KUPP$PROC PACKAGE
SYS KUPCC PACKAGE
SYS KUPF$FILE PACKAGE
PUBLIC KUPUTIL SYNONYM

REFERENCED_OWNER REFERENCED_NAME REFERENCED_TYPE
------------------------------ ------------------------------ ------------------------------
PUBLIC KUPUTIL SYNONYM
SYS KUPU$UTILITIES_INT PACKAGE
SYS KUPULIB LIBRARY
SYS X$KSPPI TABLE
SYS X$KSPPCV TABLE

16 rows selected.

SQL>

So, this package KUPU$UTILITIES_INT does not use DBMS_CRYPTO or DBMS_OBFUSCATION_TOOLKIT so its unlikely that there is any package shipped by Oracle that provides key management using wallets in the database. Because we do not see evidence of DBMS_CRYPTO used with wallets to manage symetric keys then the assumtion is that the undocumented package KUPU$UTILITIES_INT is aimed at the TDE wallet and encryption using a TDE key. But it is not documented so we dont know for sure.

Lets try some of the kupu$utility_int functions, the wallet function and the encrypt functions for fun!

In particular these are the interesting ones from earlier:

FUNCTION ENCODE RETURNS VARCHAR2
FUNCTION DH_GET_PUBLIC_KEY RETURNS VARCHAR2(1024)
FUNCTION DH_NEW_HANDLE RETURNS NUMBER
FUNCTION DH_GET_PUBLIC_KEY RETURNS VARCHAR2(1024)
FUNCTION DH_GEN_SHARED_KEY RETURNS VARCHAR2(512)
PROCEDURE DH_FREE_HANDLE
FUNCTION DH_ENCRYPT RETURNS VARCHAR2
FUNCTION DH_DECRYPT RETURNS VARCHAR2
PROCEDURE DH_CHECK_DIGESTS
PROCEDURE CHECK_ENCRYPTION_WALLET

We can try the wallet procedure:

SQL> exec sys.kupu$utilities_int.check_encryption_wallet;
BEGIN sys.kupu$utilities_int.check_encryption_wallet; END;

*
ERROR at line 1:
ORA-28365: wallet is not open
ORA-06512: at "SYS.KUPU$UTILITIES_INT", line 96
ORA-06512: at line 1


SQL>

Which wallet is not open?

SQL> set serveroutput on
SQL> @sc_print 'select * from v$encryption_wallet'
old 32: lv_str:=translate('&&1','''','''''');
new 32: lv_str:=translate('select * from v$encryption_wallet','''','''''');
Executing Query [select * from v$encryption_wallet]
WRL_TYPE : FILE
WRL_PARAMETER :
STATUS : NOT_AVAILABLE
WALLET_TYPE : UNKNOWN
WALLET_ORDER : SINGLE
KEYSTORE_MODE : UNITED
FULLY_BACKED_UP : UNDEFINED
CON_ID : 3
-------------------------------------------

PL/SQL procedure successfully completed.

SQL>

This seems to align

SQL> @sc_print 'select * from v$wallet'
old 32: lv_str:=translate('&&1','''','''''');
new 32: lv_str:=translate('select * from v$wallet','''','''''');
Executing Query [select * from v$wallet]

PL/SQL procedure successfully completed.

SQL>

SQL> @sc_print 'select * from v$encryption_keys'
old 32: lv_str:=translate('&&1','''','''''');
new 32: lv_str:=translate('select * from v$encryption_keys','''','''''');
Executing Query [select * from v$encryption_keys]

PL/SQL procedure successfully completed.

SQL>

If this function tries to use a TDE wallet then we likely would need a TDE license to create a wallet and open it. This would make use of these functions not possible even if we could find how to use them properly. Lets try the encryption:

FUNCTION DH_DECRYPT RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
SRCBUF VARCHAR2 IN
OUTFMT BINARY_INTEGER IN DEFAULT
FUNCTION DH_ENCRYPT RETURNS VARCHAR2
Argument Name Type In/Out Default?
------------------------------ ----------------------- ------ --------
HANDLE NUMBER IN
SRCBUF VARCHAR2 IN
INPFMT BINARY_INTEGER IN DEFAULT

My guess is these functions could encrypt and decrypt TDE data?

SQL> set serveroutput on
SQL> declare
2 lv_in varchar2(32767):='this is text';
3 lv_out varchar2(32767);
4 begin
5 lv_out:=kupu$utilities_int.dh_encrypt(1,lv_in,1);
6 dbms_output.put_line(lv_out);
7 end;
8 /

PL/SQL procedure successfully completed.


SQL>

The call did not fail but didnt return anything; maybe it needs the wallet?

There is one way to use a wallet to manage keys for DBMS_CRYPTO and this is to use Oracle Key Vault introduced in 21c and use the integration accelerator for DBMS_CRYPTO. There is a PL/SQL API that allows simple features such as FetchKey() and CreateKey() from a wallet held in the Oracle Key Vault. There is a sample script dbms_crypto_using_okv_keymgmt.sql available with the product demonstrating use of a wallet and DBMS_CRYPTO. A Java SDK Program KeyManager.java is supplied called okv_key_mgtm that can be modified.

Oracle Key Vault (OKV) is out of the scope for most people wanting to use a wallet as OKV is an additonally licensed appliance and is overkill if you wanted to use DBMS_CRYPTO to encrypt small amounts of data columns / rows

So in conclusion there is no simple free way to use a wallet to manage keys for use with DBMS_CRYPTO

#oracleace #sym_42 #oracle #key #vault #wallet #encryption #tde #key

Encryption Key Management with DBMS_CRYPTO

I often get asked how to use DBMS_CRYPTO to encrypt data in the Oracle database. Or I used to be asked how to use DBMS_OBFUSCATION_TOOLKIT when it was the go-to encryption in an Oracle database.

Before we go far; this is the first part of a 5 part blog around the subject of managing keys for use with DBMS_CRYPTO. Of course as I write this blog the links to the next 4 parts do not exist; I hope to come back and add these very soon. The five proposed blog parts are:

  1. Part 1: (This blog) - Discuss the problem in general and the need to encrypt data in the database

  2. Part 2 - We will present a simple solution design to store an encryption key for use with DBMS_CRYPTO and discuss some of its flaws

  3. Part 3 - Lets build a key vault

  4. Part 4 - Protecting the key vault

  5. Part 5 - Using the key vault with DBMS_CRYPTO and SQL


This method of using Oracle built in packages to encrypt data differs from TDE (Transparent Database Encryption) in that TDE is automatic as it either decrypts blocks of data returned to the SGA from data files on disk for tablespace encryption or it returns encrypted blocks and decrypts columns of data from rows of data as it needs to on demand for column based encryption.

Both TDE mechanisms are automatic and from the users perspective (The SQL executor) the data is still manipulated in clear text as normal but is in fact stored on disk encrypted. With TDE the keys are managed automatically and are generally in a wallet. There are also three layers of keys 1: Passphrase/password to open the wallet or autologin, 2: Master key stored in the wallet, 3: column keys or tablespace keys stored locally encrypted. These final keys are used to encrypt and decrypt the actual data and these keys are encrypted/decrypted by the master key. TDE uses synchronous two way encryption and whilst its ease of use is fantastic the problem - if you can call it a problem - is that the data is still available transparently via a SQL interface where the user of that SQL has rights to access encrypted data. So, if a user can select from a table in an encrypted tablespace or from a column of data that is encrypted he/she still can and can see clear text data.

The purpose of TDE is to protect the data in the datafiles at rest.

The one open gateway if you will is that the data files are encrypted - good - but the software owner (can be "oracle") is usually the only user able to access these files at the file system level - BUT that user can also simply connect to the database "/ as sysdba" and access any protected data. To prevent this in a database using TDE you must also limit the access "as sysdba" to the encrypted data. You must also use other mechanisms from normal object rights to tools such as Database Vault or VPD to limit access to the tables and therefore the encrypted data.

Of course we mentioned a wallet above used as an encryption key store but Oracle also supports the use of a Hardware Security Module (HSM) to store and protect the master key. In this case the customer can use a HSM from a third party where the master key never leaves the HSM and a C library is provided that allows TDE to talk to the HSM using standard wallets and wallet access software silently via the database. In fact in TDE the commands to open the wallet/HSM and pass the keys to be used is done silently in the background.

So, TDE is a great product and makes encrypting data easy without much effort and it also provides a way to protect data files at rest BUT what if you want to make sure that the data held in the database is normally presented encrypted to any non-authorised random access?

This is also a solution to the problem presented earlier and it means that even if someone has SQL access like with TDE they do not see clear text data unless also authorised to decrypt the data

The solutions provided by Oracle are the DBMS_CRYPTO package and in older databases the DBMS_OBFUSCATION_TOOLKIT package. The thing that stands out immediately with DBMS_CRYPTO and earlier with DBMS_OBFUSCATION_TOOLKIT is there there is no built in key management and no simple way to use or access a standard wallet. There are no mechanisms to store the encryption keys securely or provide management of keys so that a password / passphrase that unlocks the master key could be changed / cycled when needed but leaving the master key and the data encrypted with the original keys; or there is no way to cycle the master key so that again the column or row keys are left encrypted but the master key can be changed and the column keys decrypted/encrypted to allow the change but no change to the data. Finally there is no easy built in way to cycle the column keys.

Further there is no thoughts to backup of data and keys or data and old data that is encrypted say on tape with old keys.

We will not get into semantics of the use of DBMS_CRYPTO; the algorithms and other factors available as well as all of the concerns around the problems of actually encrypting data such as a join from a column that is encrypted to a clear text column or indexes on encrypted columns or the performance of dealing with now encrypted data or any changes to storage requirements such as column data types or lengths of data.

All of these are valid issues but as part of this blog and following blogs we are not even in a position to discuss these items until we can securely use DBMS_CRYPTO and keys. Performance, storage and joins are moot if we simply have to hard code a single key or pass it in. I am going to focus on the problem of keys and managing them for DBMS_CRYPTO.

Oracle does not appear to have any interfaces that would allow us to use a wallet to store and retrieve a master key for use in PL/SQL and with DBMS_CRYPTO. A quick search of the database shows:

SQL> col object_name for a30
SQL> col owner for a30
SQL> col procedure_name for a30
SQL> set lines 220
SQL> select owner,object_name,procedure_name
2 from dba_procedures
3 where procedure_name like '%WALLET%'
4 or object_name like '%WALLET%';

OWNER OBJECT_NAME PROCEDURE_NAME
------------------------------ ------------------------------ ------------------------------
SYS UTL_HTTP SET_AUTHENTICATION_FROM_WALLET
SYS UTL_HTTP SET_WALLET
SYS DBMS_ISCHED GET_AGENT_WALLET_LOCATION
SYS DBMS_GSM_FIX UPDATEWALLETFORBACKUP
SYS DBMS_NETWORK_ACL_ADMIN GET_WALLET_ACLID
SYS DBMS_NETWORK_ACL_ADMIN SET_WALLET_ACL
SYS DBMS_NETWORK_ACL_ADMIN REMOVE_WALLET_ACE
SYS DBMS_NETWORK_ACL_ADMIN APPEND_WALLET_ACL
SYS DBMS_NETWORK_ACL_ADMIN APPEND_WALLET_ACE
SYS DBMS_NETWORK_ACL_ADMIN UNASSIGN_WALLET_ACL
SYS DBMS_NETWORK_ACL_ADMIN ASSIGN_WALLET_ACL

OWNER OBJECT_NAME PROCEDURE_NAME
------------------------------ ------------------------------ ------------------------------
SYS KUPU$UTILITIES CHECK_ENCRYPTION_WALLET
SYS KUPU$UTILITIES_INT CHECK_ENCRYPTION_WALLET
XDB DBMS_XDB_ADMIN INSTALLDEFAULTWALLET

14 rows selected.

SQL>

Nothing stands out as a simple interface to create a wallet, store a key and retrieve a key as needed. We could get around this by orapki/openssl and creating a wallet and adding a key to a bucket. We could then use Java and the bouncy castle API to access the wallet and expose this to PL/SQL.

This is not ideal;

We really would like at least 3 layers of keys, one to open the wallet / vault, a master key we never see and then actual data/column keys encrypted/decrypted by the master key. Oracle with TDE does similar so we should aim for a similar goal. We also should have commands (APIs) to allow the password, master key or column keys to be changed.

We also must consider stealing of the keys or data at all stages of storage or in-flight

In other wards we want a vault that manages keys and the use of DBMS_CRYPTO.

I have done this and designed a key/crypto vault; we will go into the design in more details in the next post. It allows a password to be provided to open the vault; this is the first key and is not stored in the database or in the vault. This is similar to a wallet in that a password is used to open the wallet and this password is not stored in the wallet. We then generate and store master keys and column keys and can manage old keys through use of a manifest of sorts

Oracle provides a simple interface to encryption via DBMS_CRYPTO but leaves the hardest part to you.

Similar to audit trails in the Oracle database; all tools are provided but you need to decide what to audit and how to review that audit trail for attack

similar to securing the data; all tools are provided but you need to actually design and implement the data security.

I mention these two similar problems in other areas because we need to solve them also as part of the key vault. We need to protect and secure this critical data (keys) and also audit access.

#oracleace #sym_42 #oracle #data #encryption #security #datasecurity #keys #vault #audit #audittrails

Update on Oracle Security

PFCLScan 2025

Just an update as I have not posted too many blogs recently. I have a bag log of blog ideas to write on technical subjects directly relating to Oracle security so please watch out for those by subscribing / following / connecting on all out social channels to see the latest posts and also

  • LinkedIn: Please note I have reached the maximum of 30,000 connections BUT you can still follow me or our company page

  • FaceBook Personal Profile: Please send me a friend request and also have a look for our Facebook pages and follow them

  • Twitter / X: Please follow me

  • Youtube: This is out youtube channel, please subscribe

  • Instagram: This is our instagram channel, please follow

  • Threads: Please follow me on threads

  • BlueSky: Please follow us on BlueSky and like and share posts



We also have some pages on Facebook and Linkedin and you can find those from my profiles; we post on most channels so please give us a like and subscribe.

I have just completed the second teaching of our 3 day in person securing data in the Oracle database. We held the most recent class last week here in York, UK. The class is cradle to grave on how and why to secure data in an Oracle database. Each student got hundreds of free SQL and PL/SQL tools and scripts as well as over 840 content slides and also free 30 days licenses for PFCLScan and PFCLForensics.

We are running the class again soon again in York, must likely in May. If you are interested please let me know and book your place. The details of the class are here - NOTE: the dates are for the last teaching last week but the class and details are the same.

I am also planning a 2 day class on secure coding in PL/SQL to be held also here in York. Watch for the details of this class; each student will also get a free 30 day license for PFCLCode and PFCLObfuscate both of which will be covered in the class as they relate to secure PL/SQL. No details written down yet as a web page but coming soon but the class is written. This class will most likely be around the end of May or early June. Please let me know if you would like to book a place.

We completed version 2024 of our database scanner PFCLScan at the end of last year and all of our other products are "apps" based on the PFCLScan framework and each also had numerous updates. We did over 4000 changes to the whole package for version 2024 including more than 700 new security checks in PFCLScan and more than 300 new checks in PFCLCode.

As you can see above with the picture at the start of this post we have started on version 2025 of our product stack. There are lots of new features and updates planned and this new version will be released later this year. Watch out for more details here and our socials as we add them. We plan much more blogs to highlight the new features, checks, reports that will be added to all our products.

We have been delivering for some time PFCLATK our audit trail toolkit as a package of consulting / design work and a pre-configured audit trail toolkit. This has helped customers set up and get decent audit trails of the Oracle database engine quickly. We have done major updates of this toolkit over the last few months and it supports unified audit and we are also planning a simple "app" to add it to our PFCLScan framework. More on this soon....

We are also developing another "app" called currently PFCLUTK that allows a detailed view of all users and their rights in the database with the emphasis of what should / could be kept and what should / could be removed to allow designs of the database and applications to tend towards Least Privilege. I will show a demo of this tool here very soon and show some of its features

I am going to be at Oracle Open World London tomorrow, so if you are there are you see me, please say hello!!

I also received an from Anuj Agarwal who said my site/blog is in the top 100 Oracle blogs. Of course Tim is number 2, Jeff number 3 and I am number 10. Please give me more likes, shares, connections, follows and I can improve my position

#oracleace #sym_42 #ukoug #ocw #cloudworld #oracle #security #training #products #databreach #securedata #gdpr

AI and Oracle Security

Can we use AI in Oracle security? - yes as an answer? we can but how effective it would be means the answer is maybe? It depends on what we want to use AI for and how much data is available and whether the existing models for generative AI and augmented data via RAG (Retrieval Augmented Generation) can work.

What could we use AI for in an Oracle security sense? the obvious choices that stand out are using AI to detect wrong doing in firewalls or audit trails or using AI to detect setup anomalies in configuration. Assuming the standard generative AI model does not have enough knowledge of these topics we could create our own model and in addition teach it these things or we could use RAG to input the right knowledge (usually specialist papers, manual etc) for these things BUT these things don't using exist in any quantity. We would need a manual that describes every type of attack and then also feed the audit trails or firewall logs to this augmented AI model.

So, yes its possible

The current AI that has burst onto the scene in the last few years from OpenAI or DeepSeek has happened because of two major factors

  • The rise in availability of hardware to implement the models - graphics cards and large amounts of RAM

  • The rise in the large amounts of data freely available



  • The hardware was helped along with games using graphics cards to do matrix calculations and vector calculations and from use on things like bitcoin mining and password cracking. The rise in data is because of the colossal growth of the internet; books being digital and many more sources of knowledge that ois now digital and freely available.
    Neural Networks



    Many years ago back in 1991, I bought the above book about neural networks and also another C/C++ book that also implemented neural networks and TurboVision ( text based UI for DOS back in the Borland 3.1 development days ). The book above includes a chapter on WIZARD that was an early attempt to implement neural nets in RAM. Around the same time from 1992-1994 I also go into Fuzzy Logic and Genetic Algorithms.

    For one assignment in one class of my degree i designed a system to control car wipers based on rain fall. Not the simple setting 1, 2, 3 and 4 of early mixed speed wipers. I designed it to have a water / rain detector use used fuzzy logic to decide how fast to tell the wipers to go, or not at all. It was implemented in MatLab only and not physically but worked in the testing of the software.

    How did we get to the sudden growth of AI now with the generative models and reasoning models available today. The golden circle of the right hardware and data being available. If you look at the net then it states that chatgpt was trained on very large data sets including online, conversations and more and it was also paired with supervised learning - re-enforced - where the examples are provided the right answers.

    The fact that these models most likely use very large data sets implies that the internet was spidered and web pages parsed and knowledge extracted. Makes sense.

    Generative AI in the sense of directions, recipes, general knowledge as viewed by the general person is fine but if you play with these interfaces and ask very specific questions not supplemented by RAG data then the answers are less accurate or wrong.

    There is also a second problem that we have all seen. The rise of AI generated things. Just as examples 1) today I saw a picture that looked like ancient South American carvings except the person imaged looked like a spaceman - I have seen genuine cases that could be interpreted loosely in this way BUT this example today was sitting there firing a machine gun, fake! 2) a picture today showed ancient architecture and more modern buildings BUT the people were the wrong scale for the doors, 3) yesterday I saw a picture of a prototype diesel locomotive in Doncaster works BUT the text stated that the name plate was missing and careful viewing showed a ghost steam engine partly drawn behind.

    All these are fakes generated by AI.

    Then we have the get rich quick market, web content and social media generation and more. I have seen lots of people touting how to create images, text, posts and more using chatgpt.

    We do not know the accuracy of this fake data. The internet and the corpus of data is growing and being filled with AI and generated AI data. If the models learn or train from the internet and the internet gets corrupted with generated and fake data from AI then the training and learning is also compromised.

    This is a big problem going forwards. Yes, generative AI is great but if its polluted can we trust it.

    I think that AI will only get bigger and I can see it used in cases in Oracle security with the right data and inputs to learn. How will it perform against audit trails or firewall logs being generated in large quantities and very fast. Can AI read the data fast enough and act on it?

    #oracleace #sym_42 #oracle #database #security #ai #generative #rag


Free Licenses for Oracle Security Software

PFCLScan - Oracle Security Training in York 2025


We are holding a 3 day live, in person training event here in York, UK on March 11th to March 13th 2025 (Tuesday to Thursday). The class is taught by Pete Finnigan. The class is a unique event and will cover what you need to know to secure data in your Oracle databases.

We cover every aspect from how databases are breached, how you may have made configuration and design mistakes that could leak or lose your valuable data. We show the problems and then cover how to review your database for issues and how to secure. We focus on the things that come free with the database BUT we also cover the cost options and context based security. The class covers planning and solutions and how to secure all of your databases and make sure that they remain secure over time.

There are full class details including the agenda here.

There is a lot of material in this complete coverage of cradle to grave of securing your data.

The class is over three days and is suitable for anyone who wants to secure data or is involved in securing data. We include the course notes/slides and also hundreds of free scripts and tools. We allow plenty of time for discussions and your questions.

Also included with the class are two free engagement software licenses for our products PFCLScan and PFCLForensics that you can use to help secure your own databases.

The price is just £1095 GBP + VAT so please hurry to register your place as we have only 4 seats left. First come first served.

#oracle #security #training #hacking #datasecurity #databreach

3 Day Oracle Security Training in York in March

Our recent 3 day Oracle Security training class in York scheduled in January was popular and a lot of people who enquired for the January class asked if we could do the class again in March. I decided to do this even though I had intended to do the class as a one off in January.

The class is fast paced and detailed but is suitable for anyone who wants to secure data in their Oracle databases whether this is in the cloud or on premise. We cover the process cradle to grave of identifying, planning and securing the data and database. The class has a lot of materials, demos and free tools and scripts (around 150 scripts and tools, a lot of which we use in our own work and are not on our website).

Details of the class are on the Oracle security training in 2025 training page. There are details on that page of the agenda, materials, location and more.

This is a live class with myself teaching here in York, UK

The class is held on 3 days from the 11th March to the 13th March 2025 here at our offices in York. The price is £1,095 per person plus VAT

Please contact training@petefinnigan.com to reserve your place.
